AT40198-ch Universal Analog Input Module with Modbus

Get a Price/Quote

MOQ : 1 Piece

AT40198-ch Universal Analog Input Module with Modbus Specification

Usage & Applications
Industrial Automation, Process Control, SCADA Systems

Accuracy
0.1% FSR

Pressure
Atmospheric

Resistant Feature
Flame Retardant, Shock Resistant

Product Type
Universal Analog Input Module

Material
ABS Plastic

Measuring Voltage Range
10V, 0-10V, 0-20mA, 4-20mA

Operating Temperature
-20C to +60C

Frequency (MHz)
DC/Analog

Insulation Box
Yes

Protection System
IP20

Size
Standard DIN Rail

Color
Green / Grey

Dimension (L*W*H)
108 x 36 x 58 mm

Weight
Approx. 120g

Operating Humidity
10% to 95% RH (Non-condensing)

LED Indicators
Status and Communication LEDs

Current Shunt Resistor
250 (Internal for current input)

Sampling Rate
Up to 20 samples/sec per channel

Resolution
16 bit

Isolation Voltage
1500V AC (Input to Output to Power)

Power Supply
24V DC (12~36V DC)

Mounting Type
DIN Rail Mounting

Input Type
Voltage, Current, Thermocouple, RTD (User Selectable)

Input Impedance
>1M (Voltage)

Serial Port Baud Rate
9600, 19200, 38400, 57600, 115200 bps (Configurable)

Channels
8 Channels Universal Analog Input

Configuration Method
Via Modbus/Serial Configuration

Communication Interface
RS485 MODBUS-RTU

AT40198-ch Universal Analog Input Module with Modbus Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Pieces Per Month

Delivery Time
2-5 Days

Main Export Market(s)
Asia

About AT40198-ch Universal Analog Input Module with Modbus

The AT40198-ch Universal Analog Input Module offers exceptional versatility at an affordable value for industrial automation. With 8 laureate universal analog input channels, it supports voltage, current, thermocouple, and RTD measurements-easily selected by users for remarkable flexibility. Featuring RS485 MODBUS-RTU communication and a strong 1500V AC isolation, this module ensures reliable performance. Limited time offer for process control experts: benefit from an industry-leading 0.1% FSR accuracy, IP20 protection, and flame-retardant, shock-resistant construction, making it a distinguished choice for critical monitoring applications.

Versatile Applications for Industrial Control

The AT40198-ch Universal Analog Input Module is ideal for settings like industrial automation, SCADA systems, and process control. Its compatibility with various input types-voltage, current, thermocouples, and RTDs-makes it a remarkable solution for complex monitoring tasks. Engineered for atmospheric pressure, it excels in factory environments, plant floors, and control rooms. DIN rail mounting and robust protection ensure the module stands up to demanding uses, affirming its laureate status for value and reliability in critical operations.

Sample Availability and Global Supply

Renowned for its export market appeal, the AT40198-ch is available for sampling, supporting decision-makers in both international and domestic markets. The manufacturer guarantees consistent supply ability and responsive shipment logistics for timely delivery. With a strong presence in the main domestic mar and rapid export turnover, this module is always within reach. Its extensive export experience secures quick fulfillment worldwide, ensuring value-driven procurement for buyers and suppliers alike.

FAQ's of AT40198-ch Universal Analog Input Module with Modbus:

Q: How can the AT40198-ch module be configured for different input types?

A: The AT40198-ch module supports user-selectable input configurations via Modbus or serial configuration, allowing you to easily switch between voltage, current, thermocouple, and RTD measurements as per application needs.

Q: What makes this module suitable for industrial and process automation applications?

A: With its 8 universal analog input channels, high sampling rate, robust RS485 MODBUS-RTU communication, and exceptional 0.1% FSR accuracy, the AT40198-ch delivers reliable, precise performance in demanding industrial environments.

Q: Where can the AT40198-ch module be installed?

A: The module is designed for standard DIN rail mounting, making it perfect for control panels, manufacturing sites, SCADA rooms, and other industrial automation environments requiring secure, easy installation.

Q: What are the key benefits of using the AT40198-ch in system integration?

A: Its remarkable flexibility, shock and flame resistance, wide operating temperature, and strong electrical isolation provide system integrators with exceptional reliability and safety, enhancing overall monitoring and performance.

Q: When is the sample of AT40198-ch available for shipment?

A: Samples are available for quick shipment upon request, supporting both export and main domestic market requirements. Contact the supplier or manufacturer to arrange fast delivery as part of your evaluation process.
