AT40178-ch Analog Input Module with Modbus

Get a Price/Quote

MOQ : 1 Piece

AT40178-ch Analog Input Module with Modbus Specification

Usage & Applications
Industrial Automation, Data Acquisition, PLCs, Remote Monitoring

Accuracy
0.1% FSR

Pressure
Atmospheric

Resistant Feature
IP20 Rated, Dust and Moisture Resistance

Product Type
Analog Input Module

Material
Industrial Grade ABS/Polycarbonate

Measuring Voltage Range
0-10V DC / 4-20mA

Operating Temperature
-20C to +70C

Frequency (MHz)
50/60 Hz

Insulation Box
Yes

Protection System
Short Circuit, Over Voltage, Transient Protection

Size
Compact

Color
Grey / Black

Dimension (L*W*H)
114mm x 22.5mm x 75mm

Weight
Approx. 120g

Supported Devices
PLCs, SCADA Systems, DCS, Remote I/O

Power Consumption
< 2W

Baud Rate
1200 to 115200 bps

Response Time
<50 ms

Number of Channels
8 Channels

Communication Protocol
Modbus RTU/ASCII (RS485)

Mounting Type
DIN Rail Mountable

Isolation
2 kV Optical Isolation

Configuration
DIP Switch and Software Configurable

Power Supply
10-30V DC

Storage Temperature
-40C to +85C

LED Indicators
Power, Communication, Status

Input Signal Types
Analog Current (4-20mA) or Voltage (0-10V)

Input Impedance
>100k (Voltage), 250 (Current)

AT40178-ch Analog Input Module with Modbus Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Pieces Per Month

Delivery Time
2-5 Days

Main Export Market(s)
Asia

About AT40178-ch Analog Input Module with Modbus

Buy Online the monumental AT40178-ch Analog Input Module with Modbus-crafted for preeminent performance in demanding industrial environments. This gilt-edged module features 8 high-accuracy analog input channels, accepting both current (4-20mA) and voltage (0-10V) signals. Take advantage of robust 2kV optical isolation and IP20 protection. Enjoy DIP switch and software configurability, a compact ABS/polycarbonate body, and LED status indicators. Now on Special Clearance: Ideal for PLCs, SCADA/DCS, and remote monitoring, direct from an exporter, manufacturer, and supplier in China.

Exceptional Features for Flexible Industrial Use

The AT40178-ch Analog Input Module stands out for its versatile support of either analog current or voltage inputs across 8 channels, making it invaluable for data acquisition and automation. Its formidable 2kV isolation, rugged IP20 dust and moisture resistance, and configurable settings guarantee reliability and safety. Perfect for PLCs, SCADA systems, remote I/O, or DCS applications, this module is sized for DIN rail mounting in compact industrial panels.

Reliable Supply, Certified Quality, and Responsive Delivery

With robust supply ability and direct export from China, the AT40178-ch is always available at an attractive asking price. Certified for industry standards, this module is favored on the main domestic market and can be delivered rapidly, with secure drop-off options for bulk or single orders. Order now to secure dependable analog data acquisition, whether upgrading an automation line or maintaining high-capacity control systems.

FAQ's of AT40178-ch Analog Input Module with Modbus:

Q: How does the AT40178-ch support different input signals?

A: The AT40178-ch module accepts both analog current (4-20mA) and voltage (0-10V) signals, allowing users to configure each channel according to the needs of their specific data acquisition or control system.

Q: What safety features are included in this module?

A: Safety is ensured with 2kV optical isolation, a robust insulation box, short circuit and overvoltage protection, and IP20-rated dust and moisture resistance, making it ideal for rigorous industrial environments.

Q: Where can the AT40178-ch Analog Input Module be installed?

A: This compact module is designed for DIN rail mounting and can be seamlessly integrated into PLC panels, SCADA system cabinets, DCS racks, or remote monitoring sites within industrial automation infrastructures.

Q: What is the process for configuring the input channels?

A: Channels can be easily set up using DIP switches or via software, giving users flexible options to tailor the module to their preferred signal types and application requirements.

Q: What are the main benefits of choosing the AT40178-ch module?

A: Its high accuracy (0.1% FSR), fast response time (<50ms), multi-protocol Modbus communication, and durable industrial-grade build ensure reliable, uninterrupted data collection and system performance for automation projects.
