AT2817Precision LCR Meter

Get a Price/Quote

MOQ : 1 Piece

AT2817Precision LCR Meter Specification

Accuracy
Basic accuracy 0.05%

Batteries Type
Mains Operated

Resistant Feature
EMI Shielded

Usage & Applications
Capacitance, Inductance & Resistance Measurement in Laboratories and Production

Product Type
Precision LCR Meter

Material
Industrial Grade Components

Measuring Voltage Range
0.1V, 0.3V, 1V (RMS)

Operating Temperature
0C to 40C

Frequency (MHz)
10Hz to 100kHz (0.01-100kHz)

Insulation Box
Yes

Protection System
Full Protection Circuitry

Size
Standard Laboratory Size

Color
Grey

Dimension (L*W*H)
350mm 320mm 100mm

Weight
Approx. 4.5kg

Optional Accessories
SMD Test Fixture, Temperature Probe

Safety
Conforms to CE Requirements

Measurement Range
R: 0.01 - 99.99 M, C: 0.01 pF - 99999 F, L: 0.01 H - 99999 H

Power Supply
AC 100V-240V, 50/60Hz

Fixture Type
Four-Terminal Kelvin Clip (Standard)

Comparator Function
Available (PASS/FAIL Judgement)

Interface
RS232, Handler, USB Device

Test Signal Frequency
10Hz, 100Hz, 120Hz, 1kHz, 10kHz, 100kHz

Display
4.3-inch LCD with Backlight

Data Storage
Internal Memory for Measured Data

Test Speed
Fast, Medium, Slow (up to 13 times/sec)

Calibration
Auto and Manual

AT2817Precision LCR Meter Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Pieces Per Month

Delivery Time
2-5 Days

Main Export Market(s)
Asia

About AT2817Precision LCR Meter

Experience the formidable capabilities of the AT2817Precision LCR Meter, where order meets innovation. Featuring a striking 4.3-inch LCD with backlight, this device delivers extraordinary precision across an exceptional measurement range for resistance, capacitance, and inductance. With rapid test speeds-up to 13 times per second-and versatile test signal frequencies, it is engineered for both ephemeral measurements and continuous lab work. EMI shielding and a full protection circuit ensure unmatched reliability, while the triumphant internal memory simplifies data management. This is the featured solution for demanding laboratory and production environments.

AT2817Precision LCR Meter: Usage & Competitive Advantages

Ideal for both specific and general use, the AT2817Precision LCR Meter is designed for precise capacitance, inductance, and resistance measurement in laboratories and production environments. Its versatile range, automatic/manual calibration, and comparator function enable high-order accuracy and reliability. Industrial-grade construction and EMI shielding provide formidable durability, while comprehensive interface options meet broad application needs, distinguishing it as an extraordinary solution among featured instruments.

Domestic Market, Supply, and Delivery Overview

Serving major domestic markets with robust supply ability, the AT2817Precision LCR Meter ensures streamlined order processing and efficient delivery times. With an agile procurement and outlay system, clients are assured dependable access to products, whether for bulk procurement or special projects. Orders are managed to minimize lead time and maximize satisfaction, reinforcing the meter's reputation as a trusted resource for laboratories and manufacturing environments throughout China.

FAQ's of AT2817Precision LCR Meter:

Q: How does the AT2817Precision LCR Meter ensure accurate measurements?

A: The AT2817Precision LCR Meter utilizes both auto and manual calibration functions, a basic accuracy of 0.05%, and a comparator feature for PASS/FAIL judgment, ensuring that every measurement is highly precise and reliable.

Q: What applications is the AT2817Precision LCR Meter best suited for?

A: This instrument is primarily used for measuring capacitance, inductance, and resistance, making it ideal for laboratory testing, product development, and quality control in production environments.

Q: When is the internal memory function most beneficial?

A: The internal memory is especially useful during high-frequency measurement sessions or prolonged laboratory work, enabling users to effortlessly store, recall, and manage measured data without interruptions.

Q: Where can the AT2817Precision LCR Meter be used and installed?

A: Designed for standard laboratory size requirements, this meter fits seamlessly into laboratory benches, research departments, or production test stations, and is suitable for use wherever precise electrical measurements are essential.

Q: What is the process for order placement and delivery?

A: Orders are processed systematically to ensure accuracy and timeliness. Once an order is placed, products are dispatched within the stipulated delivery period, supported by efficient supply chain management for streamlined fulfillment.

Q: How does the protection system enhance user safety?

A: The full protection circuitry and compliance with CE requirements safeguard both the device and its users, making it reliable for consistent use in varied operational environments.
