AT3810APrecision LCR Meter

Get a Price/Quote

MOQ : 1 Piece

AT3810APrecision LCR Meter Specification

Usage & Applications
Component impedance measurement, quality control, lab analysis

Accuracy
Basic accuracy: 0.1%

Resistant Feature
Shock-resistant enclosure

Batteries Type
AC powered; no batteries required

Product Type
Precision LCR Meter

Material
Industrial-grade ABS and metal housing

Measuring Voltage Range
0.1V, 0.3V, 1V

Operating Temperature
0C to 40C

Frequency (MHz)
0.1 to 100kHz (0.1MHz)

Insulation Box
Yes

Protection System
Built-in protection circuit for overload and short-circuit

Size
Standard Bench-top

Color
White/Blue

Dimension (L*W*H)
355mm 340mm 110mm

Weight
Approx. 4.2kg

Calibration
Automatic and manual calibration supported

Display Type
Large backlit LCD display

Measurement Signal
Programmable test signal level

Comparator Function
Built-in comparator for bin-sorting

Data Storage
Stores up to 1000 groups of test data

Power Supply
AC 100V-240V, 50/60Hz

Interface
RS232, Handler interface, and optional GPIB

Test Speed
Fast (up to 13 measurements/sec)

Measurement Parameters
L (Inductance), C (Capacitance), R (Resistance), Q, D, ESR, and Z

Accessories Included
Standard test leads, user manual, power cord

AT3810APrecision LCR Meter Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Pieces Per Month

Delivery Time
2-5 Days

Main Export Market(s)
Asia

About AT3810APrecision LCR Meter

The AT3810APrecision LCR Meter showcases top-drawer technology, designed for highlighted performance in electronic testing. This exclusive instrument offers lustrous measurement accuracy (0.1%) for L, C, R, Q, D, ESR, and Z parameters, displayed on a brilliant large backlit LCD. With a valiant test speed of up to 13 measurements per second and programmable signal levels, this purchase ensures efficiency in your processes. Featuring data storage for 1000 test groups, shock-resistant enclosure, and versatile connectivity options, it is an ideal solution for exporters, manufacturers, and lab professionals seeking excellence.

Unmatched Features and Industrial Applications

AT3810APrecision LCR Meter stands out with its robust ABS/metal construction, insulation box, and overload/short-circuit protection system. It is tailored for plant applications, including production line quality control, research labs, and component manufacturing. Its use type is dedicated to both benchtop and industrial environments, offering seamless data handling, calibration flexibility, and a durable, shock-resistant build that endures challenging conditions.

Handled With Care: Payment, Certifications & Packaging

Upon proposal amount approval, the AT3810APrecision LCR Meter is delivered with full industry certifications and quality documentation. Each unit is carefully packaged in a secure insulation box to ensure safe handover and prevent transit damage. Our export-ready approach guarantees reliable fulfillment for suppliers, manufacturers, or distributors. Secure payment terms support seamless transactions, making your purchase both protected and convenient.

FAQ's of AT3810APrecision LCR Meter:

Q: How does the AT3810APrecision LCR Meter ensure measurement accuracy?

A: The AT3810APrecision LCR Meter features a basic accuracy of 0.1% and supports automatic and manual calibration, ensuring precise measurement outcomes across its L, C, R, Q, D, ESR, and Z parameters.

Q: What types of applications is this LCR Meter best suited for?

A: This instrument is ideal for component impedance measurement, laboratory analysis, manufacturing quality control, and industrial plant testing, thanks to its fast measurement speed and durable build.

Q: When can I expect delivery after making a purchase?

A: Delivery schedules are established after confirmation of the proposal amount and payment terms, ensuring a prompt and reliable handover to your facility.

Q: Where can the data from the AT3810APrecision LCR Meter be stored and accessed?

A: The meter can store up to 1000 groups of test data internally, with access facilitated via a large LCD display and connectivity options like RS232, handler interface, and optional GPIB.

Q: How does the built-in comparator function aid in quality control?

A: The built-in comparator enables automatic bin-sorting, streamlining the process of component assessment and helping operators quickly identify and segregate parts based on measurement outcomes.

Q: What protection features are integrated into the LCR Meter?

A: The AT3810APrecision LCR Meter includes a shock-resistant enclosure, an insulation box, and a built-in protection circuit to safeguard against overloads and short-circuits, enhancing its reliability and longevity.
