AT86510Multi channel DC electronic load

Get a Price/Quote

MOQ : 1 Piece

AT86510Multi channel DC electronic load Specification

Pressure
Atmospheric

Resistant Feature
Corrosion Resistant Front Panel

Usage & Applications
Battery, Power Supply, Charger, Adapter Testing, Lab & Industrial Use

Accuracy
0.05%+0.05%FS

Product Type
Multi Channel DC Electronic Load

Material
Metal Casing, High-quality Components

Measuring Voltage Range
0~120V

Operating Temperature
0C to 40C

Frequency (MHz)
50/60 Hz

Insulation Box
Yes

Protection System
Over Voltage, Over Current, Over Power, Over Temperature, Reverse Polarity

Size
Standard

Color
Grey/White

Dimension (L*W*H)
485 x 444 x 140 mm

Weight
Approx. 20 kg

Cooling System
Intelligent Fan Cooling

Maximum Power Per Channel
400W

Control Modes
CC/CV/CP/CR (Constant Current/Voltage/Power/Resistance)

Display Type
Large LCD digital display

Load Regulation
0.03%+10mV

Data Storage
Yes, built-in memory

Working Humidity
80% RH

Programming Resolution
Current/Voltage: 1mA/1mV

Line Regulation
0.01%+2mV

Input Current Range
0~40A

Power Supply Voltage
AC 220V 10%, 50/60Hz

Remote Control
Supported

Interface
RS232, USB, LAN

Channels
Up to 10 independent channels

AT86510Multi channel DC electronic load Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
50 Pieces Per Month

Delivery Time
2-5 Days

Main Export Market(s)
Asia

About AT86510Multi channel DC electronic load

The AT86510 Multi-Channel DC Electronic Load is a peerless and reliable solution, highly recommended for laboratory and industrial applications. Featuring up to 10 independent channels and a matchless 400W maximum power per channel, this product offers remarkable flexibility for battery, charger, and power supply testing. Enjoy order and precision through advanced control modes (CC, CV, CP, CR) and a large LCD display. With excellent data storage, remote control options, and robust protection systems, this device is perfect to procure for professionals seeking unmatched performance and safety in demanding environments.

Diverse Applications for Professionals

The AT86510 Multi-Channel DC Electronic Load finds wide application in battery, charger, power supply, and adapter testing environments. Extensively used by engineers, researchers, and quality controllers, it serves laboratories, research centers, and industrial facilities seamlessly. The unit's versatile design fulfills the stringent requirements of modern testing, ensuring consistent performance and reliable results in both R&D and production media where accuracy and safety are critical.

Packaging & Market Supply Details

Each AT86510 unit is carefully packed using industrial-grade materials to ensure safety during transit. We supply to all major domestic markets and welcome sample requests for evaluation purposes. Samples are offered based on project scope and availability; please contact us to estimate costs and schedule. As an esteemed exporter, manufacturer, and supplier in China, we guarantee prompt delivery and professional packaging tailored to client requirements.

FAQ's of AT86510Multi channel DC electronic load:

Q: How many independent channels does the AT86510 Multi-Channel DC Electronic Load provide?

A: The AT86510 offers up to 10 independent channels, allowing simultaneous testing of multiple devices or circuits with enhanced flexibility.

Q: What types of testing applications is this electronic load best suited for?

A: It is ideal for battery, power supply, charger, and adapter testing, commonly used in laboratories, industrial settings, and R&D environments.

Q: What control modes are available on the AT86510 device?

A: The device supports four control modes: Constant Current (CC), Constant Voltage (CV), Constant Power (CP), and Constant Resistance (CR), making it suitable for diverse testing needs.

Q: How does the protection system ensure safe operation?

A: The AT86510 features over-voltage, over-current, over-power, over-temperature, and reverse polarity protection to safeguard your equipment and maintain operational safety.

Q: What is the process for ordering and receiving a sample unit?

A: To procure a sample, contact our sales team with your requirements. We offer samples based on project scale and can estimate timelines and costs upon request.
