AT520LBattery milliohm Meter

Get a Price/Quote

MOQ : 1 Piece

AT520LBattery milliohm Meter Specification

Batteries Type
Rechargeable Li-ion Battery

Pressure
Ambient (Not Rated for Pressure Environments)

Resistant Feature
Shock Resistant Housing

Accuracy
0.5% of Reading

Usage & Applications
Battery Internal Resistance and Milliohm Measurement

Product Type
Battery Milliohm Meter

Material
ABS Plastic

Measuring Voltage Range
DC 3V to 18V

Operating Temperature
0C to 40C

Frequency (MHz)
DC Measurement (Not Applicable)

Insulation Box
Yes

Protection System
Fuse and Overload Protection

Size
Handheld/Portable

Color
Blue/Black

Dimension (L*W*H)
230 mm x 190 mm x 90 mm

Weight
Approx. 1.2 kg

Data Storage
Up to 99 Groups

Test Current
50mA/100mA/1A Selectable

Charging Mode
USB Charger Supported

Auto Power Off
Yes

Measurement Range
0.01 m to 200

Data Hold Function
Yes

Accessories Included
Kelvin Clip Leads, User Manual, Charger Adapter

Display Type
Large Digital LCD

Safety Standard
CE Certified

Input Terminal
4-Wire Kelvin Connection

AT520LBattery milliohm Meter Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
50 Pieces Per Month

Delivery Time
2-5 Days

Main Export Market(s)
Asia

About AT520LBattery milliohm Meter

Experience the superior performance of the AT520LBattery Milliohm Meter, the trending choice for precise battery resistance measurements. Famed for its large digital LCD and fresh design, this hot-selling, handheld meter provides superlative accuracy (0.5%) across a range of 0.01 m to 200. With selectable test currents, robust shock-resistant ABS housing, and advanced data storage for up to 99 groups, it's perfect for professionals seeking exceptional reliability. CE-certified and equipped with Kelvin Clip Leads, this portable device ensures safe, efficient, and consistent results for battery manufacturers, exporters, and suppliers worldwide.

Versatile Applications in Battery Internal Resistance Testing

The AT520LBattery Milliohm Meter is used for rapid and accurate measurement of battery internal resistance in both commercial and industrial settings. Its compact size and precise data hold function make it ideal for usage in testing labs, battery manufacturing, and quality assurance processes. Designed for active use, it supports technicians and engineers by delivering dependable results for battery maintenance, diagnostics, and production line checks.

Export Quality Assurance and Reliable Global Logistics

With a strong supply ability, the AT520LBattery Milliohm Meter caters to major export markets across Asia, Europe, and North America. Secure shipping, reliable logistics, and clear charging procedures ensure timely and safe product delivery. Certified with CE standards, each meter is carefully packed with essential accessories and insulation, promising users peace of mind and regulatory compliance in every shipment.

FAQ's of AT520LBattery milliohm Meter:

Q: How does the AT520LBattery Milliohm Meter store and manage test data?

A: The meter features a data storage system capable of saving up to 99 groups of measurement results. With its clear digital LCD display, users can conveniently review past readings and ensure accurate logging for future reference or reporting.

Q: What are the main applications or industries for the AT520LBattery Milliohm Meter?

A: This meter is primarily used in battery testing, manufacturing, and maintenance. It is also valuable for research labs, quality control departments, and any commercial operation requiring precise milliohm measurements of batteries.

Q: When should I use the data hold and auto power-off functions?

A: The data hold feature is useful for securing a measurement on the display for review or transcription, while the auto power-off function automatically conserves battery life by shutting down the device after a period of inactivity.

Q: Where can I charge the AT520LBattery Milliohm Meter?

A: The device supports USB charging, allowing it to be conveniently powered from standard USB charger adapters, computers, or portable power banks, providing flexibility in various environments.

Q: What safety features are included with this meter?

A: The meter is CE certified and includes fuse and overload protection systems. The shock-resistant ABS housing and high-quality insulation box further enhance user safety and device durability during operation.

Q: How does the 4-wire Kelvin connection benefit measurement accuracy?

A: The 4-wire Kelvin input terminal minimizes errors by eliminating the resistance of the test leads from the measurement, delivering higher accuracy, especially crucial for low-resistance testing like battery internal resistance.
