AT5120Multi-channel Resistance Meter

Get a Price/Quote

MOQ : 1 Piece

AT5120Multi-channel Resistance Meter Specification

Usage & Applications
Precision resistance measurement in laboratories, factories, and automated production lines

Accuracy
0.05% 3 digits

Batteries Type
Mains operated

Resistant Feature
High insulation, dust-proof front panel

Product Type
Multi-channel Resistance Meter

Material
ABS Housing

Measuring Voltage Range
DC 0~20V (Selectable)

Operating Temperature
0C~40C

Frequency (MHz)
DC measurement only

Insulation Box
Available

Protection System
Built-in overload and short-circuit protection

Size
Standard Bench-top

Color
White

Dimension (L*W*H)
325 mm x 290 mm x 105 mm

Weight
Approx. 3.2 kg

Safety Compliance
IEC/EN61010-1

Measuring Range
0.01 m to 2 M

Power Supply
AC 220V 10%, 50Hz

Sampling Rate
Up to 50 readings/second

Standard Accessories
4-wire kelvin probe, RS232 cable, power cord, user manual

Data Interface
RS232/Handler/USB (optional)

Zero Adjustment
Manual & Auto available

Display
LCD Digital Backlight Display

Storage Capacity
Internal storage for test data

Number of Channels
4 Channels (Expandable)

Calibration
Internal self-calibration function

AT5120Multi-channel Resistance Meter Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Pieces Per Month

Delivery Time
2-5 Days

Main Export Market(s)
Asia

About AT5120Multi-channel Resistance Meter

Favorable reviews make the AT5120 Multi-channel Resistance Meter a sterling choice for professionals in need of precision and reliability. Boasting a superb, polished design, this benchtop device features an LCD digital backlight display and can be personalised to suit unique workflow demands with its expandable four-channel configuration. Enjoy the accuracy of 0.05% + 3 digits and up to 50 readings per second, allowing for rapid, dependable results. Support for RS232, Handler, and USB interfaces (optional) ensures versatile data management. Purchase includes standard accessories, durable ABS housing, and robust safety compliance, providing peace of mind and lasting value.

Applications and Advanced Features

Perfect for laboratories, manufacturing plants, and automated production lines, the AT5120 Multi-channel Resistance Meter delivers reliable, precision resistance measurements. Experience the benefit of high insulation and a dust-proof front panel, ensuring robust performance in varied environments. Its usage is seamless with both manual and auto zero adjustment, along with an internal self-calibration feature. The compact, bench-top form factor, combined with comprehensive safety and storage features, makes it ideal for regular and demanding operational routines.

Sample Policy, Availability, and Packaging

Samples of the AT5120 Multi-channel Resistance Meter are available for preliminary valuation upon request. Estimated time of arrival for samples depends on location and current export schedules, ensuring timely delivery to all regions. Each unit is professionally packaged in a sturdy insulated box to guarantee optimum condition upon receipt. Our efficient handling and secure packaging process reinforce the product's reputation as a superb and reliable measuring solution, directly from the manufacturer, supplier, and exporter in China.

FAQ's of AT5120Multi-channel Resistance Meter:

Q: How does the AT5120 Multi-channel Resistance Meter ensure accurate measurements?

A: The AT5120 features internal self-calibration, manual and auto zero adjustment, and a precise accuracy of 0.05% + 3 digits to guarantee reliable, consistent resistance measurements.

Q: What are the main benefits of using a multi-channel resistance meter in a manufacturing environment?

A: Using a multi-channel resistance meter like the AT5120 allows for simultaneous measurements across up to four channels (expandable), increasing productivity and ensuring superb data collection accuracy in demanding production lines.

Q: What process should I follow to request a sample unit?

A: Contact the exporter, manufacturer, or supplier directly to request a sample. Provide your details, and a sample will be sent per the current policies. The estimated arrival time will be communicated after order confirmation.

Q: Where can the AT5120 Resistance Meter be applied?

A: It is ideal for precision resistance measurement in laboratories, factories, quality assurance departments, and automated production lines, thanks to its high durability and versatile operation.

Q: How do I access stored test data from the meter?

A: Stored test data can be accessed through the instrument's internal memory and exported via available data interfaces such as RS232, Handler, or optional USB.

Q: What features make the AT5120 safe and robust?

A: The meter is compliant with IEC/EN61010-1 safety standards, includes built-in overload and short-circuit protection, features a dust-proof front panel, and is constructed with a strong, insulating ABS housing.
