AT4524Multi-Channel Temperature Meter

Get a Price/Quote

MOQ : 1 Piece

AT4524Multi-Channel Temperature Meter Specification

Usage & Applications
Industrial Temperature Measurement, Data Logging, Laboratory Use, Process Control

Pressure
Ambient, not pressure-rated

Accuracy
0.3% of reading +1 digit

Batteries Type
Rechargeable Lithium or AC Mains

Resistant Feature
Corrosion Resistant

Product Type
Multi-Channel Temperature Meter

Material
ABS Plastic

Measuring Voltage Range
-200C to 1800C (depending on sensor type)

Operating Temperature
0C to 50C

Frequency (MHz)
50/60 Hz

Insulation Box
Available

Protection System
Overload, Reverse Polarity

Size
Compact

Color
Gray

Dimension (L*W*H)
235 x 180 x 65 mm

Weight
1.5 kg

Channels
4 Independent Measurement Channels

Mounting
Bench-top or Wall Mountable

Sampling Rate
Approx. 2 samples/sec per channel

Display
Large Backlit LCD Display

Alarm Function
High/Low Set Alarm Outputs

Calibration
Factory Calibrated, User Calibration Option

Sensor Compatibility
Supports K, J, T, E, R, S, N, B Type Thermocouples

Power Supply
100-240V AC, 50/60Hz

Communication Interface
RS232/USB

Input Impedance
>10 M

Data Storage
Internal Data Logging up to 10,000 records

AT4524Multi-Channel Temperature Meter Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
50 Pieces Per Month

Delivery Time
2-5 Days

Main Export Market(s)
Asia

About AT4524Multi-Channel Temperature Meter

The acclaimed AT4524 Multi-Channel Temperature Meter stands in the spotlight with its unrivaled performance and instant savings for industrial and laboratory environments. Featuring four independent measurement channels and valiant support for a wide spectrum of thermocouples (K, J, T, E, R, S, N, B types), this towering instrument boasts a large, backlit LCD, robust internal data logging for 10,000 records, and versatile RS232/USB connectivity. Designed for both bench-top and wall mounting, it's factory-calibrated and user-adjustable, delivering accurate readings from -200C to 1800C. Its corrosion-resistant ABS build and advanced protection embody reliability.

AT4524-Advantage, Features, and Durable Material

The AT4524 Multi-Channel Temperature Meter offers towering accuracy at 0.3% +1 digit, ensuring highly reliable readings. Constructed from valiant, corrosion-resistant ABS plastic, its sturdy insulation box further enhances safety. Notable features include instant multi-sensor compatibility, a large backlit LCD, data logging, and robust alarm functions. The overload and reverse polarity protection systems provide unrivaled operational security, making the AT4524 ideal for industrial, laboratory, and process control settings.

Packaging, Certification, and Delivery Details at a Glance

Each AT4524 meter is securely packaged to safeguard against transit damage and is delivered with a full set of accessories. With fast processing rates and competitive quotations, shipments are efficiently handled worldwide. Certified for quality assurance, the AT4524 typically arrives within 7-15 days from the order date, depending on destination. Our streamlined logistics process guarantees that every unit is delivered on time and in peak condition, adhering strictly to industry standards.

FAQ's of AT4524Multi-Channel Temperature Meter:

Q: How does the AT4524 measure temperatures across multiple points?

A: The AT4524 features four independent measurement channels, allowing users to monitor multiple temperature points simultaneously. Each channel can connect to a different thermocouple, providing flexible and efficient data collection in complex environments.

Q: What sensors are compatible with the AT4524 Multi-Channel Temperature Meter?

A: This temperature meter supports a wide range of thermocouples, including types K, J, T, E, R, S, N, and B, accommodating diverse temperature measurement requirements across various processes.

Q: When should I use the alarm function of the AT4524?

A: The alarm function should be employed when high or low temperature thresholds are critical for your application. It alerts users if temperatures fall outside preset ranges, ensuring process safety and swift response to anomalies.

Q: Where can the AT4524 be mounted or installed?

A: The meter is designed with flexibility in mind and can be conveniently mounted on a bench-top for laboratory tasks or attached to a wall for space-saving industrial setups.

Q: What is the data logging process with the AT4524?

A: The AT4524 internally logs temperature data for up to 10,000 records. Data retrieval is seamless via RS232 or USB interfaces, supporting both real-time monitoring and later analysis.

Q: How does the protection system benefit users?

A: The protection system shields against overload and reverse polarity, safeguarding both the device and connected equipment. This reduces downtime and ensures long-term reliability in demanding environments.
